DNA 570XC

DNA 570XC

Outboard Motor

100-135HP

550kg

DNA 570XC

From $59,697.00

Our 5.7m cuddy is big enough to comfortably fish four adults and provides great protection from the elements, glass screens provide excellent vision , Seats bases are standard with open area underneath to allow stowage of chilly bins. Battery secured away in transom lockers with 2 x access hatches. Tapering pontoons for that sleek appearance and non-pounding ride. High sides give great protection from spray and provide ample storage around the boat for all types of gear meaning a clutter free deck and more room to fish!!! This boat is still towable on a single axle trailer and can be launched and handled by one person.

DNA 570XC Specs

Length5.7
Recommended HP100HP
Maximum HP135HP
Leg length25
External beam2.27MTR
Internal beam1.65MTR
Deadrise (At transom)20
Tube thickness3mm
Hull thickness4mm
Dry weight550Kg
Tow weight1195Kg
Length on trailer6.80MTR

DNA 570XC Features

“DNA” Graphics
4mm hull
Transducer bracket
Cuddy Shelves
Transom locker & 2 X hatches
Bilge pump & well
X Series hull & full flat floor
Tie down points
High sides and storage
Drain Bung
Sealed Treadplate floor
NFB Steering
Nav light / anchor light
Battery master switch & wiring loom
Open underneath seat bases
Sliding bolster seats
Anchor bin
4x rod holders & cup holders
Outboard pod
Transom Platforms
Non skid walk around bow
Bow handrails
Smooth touch flat bar stern rails
  • “DNA” Graphics
  • 4mm hull
  • Transducer bracket
  • Cuddy Shelves
  • Transom locker & 2 X hatches
  • Bilge pump & well
  • X Series hull & full flat floor
  • Tie down points
  • High sides and storage
  • Drain Bung
  • Sealed Treadplate floor
  • NFB Steering
  • Nav light / anchor light
  • Battery master switch & wiring loom
  • Open underneath seat bases
  • Sliding bolster seats
  • Anchor bin
  • 4x rod holders & cup holders
  • Outboard pod
  • Transom Platforms
  • Non skid walk around bow
  • Bow handrails
  • Smooth touch flat bar stern rails

Note: Specifications and equipment may change at any time without notice. Photographs shown may include non-standard extras. Please consult your DNA Boats Dealer for specific model information.

DNA 570XC Gallery

DNA 570XC Additional Options

Railblaza baitboard
Tube matting on cockpit floor
Baitboard including 5 X rod holders
U DEK matting on high sides
Livebait tank / walk through
Walk through transom
Rear sliding bench seat
Railblaza attachments
V berth infills (each)
Simrad electronics
Maxwell anchor winch and anchor
Underfloor Storage
Dual batteries
Vee berth & 3 X squabs
U DEK custom decking
Vinyl wrap topsides & pontoons
Vinyl wrap top sides
Wash down pump
Extra rod holders in gunnels x 2
Soft ride pedestal seats (each)
DNA custom alloy trailer upgrade
Hydraulic Steering
Dive ladder
Lighting
Keel wear strip
Front access hatch
Full cabin upholstery
  • Railblaza baitboard
  • Tube matting on cockpit floor
  • Baitboard including 5 X rod holders
  • U DEK matting on high sides
  • Livebait tank / walk through
  • Walk through transom
  • Rear sliding bench seat
  • Railblaza attachments
  • V berth infills (each)
  • Simrad electronics
  • Maxwell anchor winch and anchor
  • Underfloor Storage
  • Dual batteries
  • Vee berth & 3 X squabs
  • U DEK custom decking
  • Vinyl wrap topsides & pontoons
  • Vinyl wrap top sides
  • Wash down pump
  • Extra rod holders in gunnels x 2
  • Soft ride pedestal seats (each)
  • DNA custom alloy trailer upgrade
  • Hydraulic Steering
  • Dive ladder
  • Lighting
  • Keel wear strip
  • Front access hatch
  • Full cabin upholstery
